R88減速機詳細信息
R88減速機
訂購熱線：13360667204
R88減速機傳動比計算：齒輪減速馬達
輸送帶參數：輪子直徑180，負載4噸，一分鐘走15米
15米÷（0.18輪子直徑×3.14）=26.53轉每分鐘
4噸換算成N=40000N
40000×0.09輪子半徑×0.06摩擦系數=216N.m
通常確保萬無一失，我們會把輸出扭矩放大兩倍216×2=432N.m
電機轉數1400÷輸出轉數26.53=52.77比
432N.m輸出扭矩÷52.77比=8.19N.m電機扭矩
8.19N.m電機扭矩換算成功率1.299KW以上
對應的R88減速機選型參數：
型號：R89-B1.5KW
減速比：52.82
輸出轉數：27轉每分鐘
輸出扭矩：525N.m
安全系數：2.90
R88減速機平面圖紙：輸出軸Φ20+鍵2.5（可定做），高134*寬135*長174（帶輸出軸）R系列減速機
R88臥式硬齒面斜齒輪減速機型號：
R87FDM100L4,R87FDM100LC4,R87FDM100LS4,R87FDM100M4,R87FDM112M4,R87FDM132L4,R87FDM132M4,R87FDM132MC4,R87FDM132ML4,R87FDM132S4,R87FDM160L4,R87FDM160M4,R87FDM160MC4,R87FDM160S4,R87FDM180L4,R87FDM180LC4,R87FDM180M4,R87FDM180S4,R87FDM200L4,R87FDM71D4,R87FDM71M4,R87FDM71MS4,R87FDM71S4,R87FDM80K4,R87FDM80M4,R87FDM80MK4,R87FDM80N4,R87FDM80S4,R87FDM90L4,R87FDM90M4,R87FDM90S4,R87FDR100L4,R87FDR100LC4,R87FDR100LS4,R87FDR100M4,R87FDR112M4,R87FDR132L4,R87FDR132M4,R87FDR132MC4,R87FDR132ML4,R87FDR132S4,R87FDR160L4,R87FDR160M4,R87FDR160MC4,R87FDR160S4,R87FDR180L4,R87FDR180LC4,R87FDR180M4,R87FDR180S4,R87FDR200L4,R87FDR71D4,R87FDR71M4,R87FDR71MS4,R87FDR71S4,R87FDR80K4,R87FDR80M4,R87FDR80MK4,R87FDR80N4,R87FDR80S4,R87FDR90L4,R87FDR90M4,R87FDR90S4,R87FDRE100L4,R87FDRE100LC4,R87FDRE100LS4,R87FDRE100M4,R87FDRE112M4,R87FDRE132L4,R87FDRE132M4,R87FDRE132MC4,R87FDRE132ML4,R87FDRE132S4,R87FDRE160L4,R87FDRE160M4,R87FDRE160MC4,R87FDRE160S4,R87FDRE180L4,R87FDRE180LC4,R87FDRE180M4,R87FDRE180S4,R87FDRE200L4,R87FDRE71D4,R87FDRE71M4,R87FDRE71MS4,R87FDRE71S4,R87FDRE80K4,R87FDRE80M4,R87FDRE80MK4,R87FDRE80N4,R87FDRE80S4,R87FDRE90L4,R87FDRE90M4,R87FDRE90S4,R87FDRN100L4,R87FDRN100LC4,R87FDRN100LS4,R87FDRN100M4,R87FDRN112M4,R87FDRN132L4,R87FDRN132M4,R87FDRN132MC4,R87FDRN132ML4,R87FDRN132S4,R87FDRN160L4,R87FDRN160M4,R87FDRN160MC4,R87FDRN160S4,R87FDRN180L4,R87FDRN180LC4,R87FDRN180M4,R87FDRN180S4,R87FDRN200L4,R87FDRN71D4,R87FDRN71M4,R87FDRN71MS4,R87FDRN71S4,R87FDRN80K4,R87FDRN80M4,R87FDRN80MK4,R87FDRN80N4,R87FDRN80S4,R87FDRN90L4,R87FDRN90M4,R87FDRN90S4,R87FDRS100L4,R87FDRS100LC4,R87FDRS100LS4,R87FDRS100M4,R87FDRS112M4,R87FDRS132L4,R87FDRS132M4,R87FDRS132MC4,R87FDRS132ML4,R87FDRS132S4,R87FDRS160L4,R87FDRS160M4,R87FDRS160MC4,R87FDRS160S4,R87FDRS180L4,R87FDRS180LC4,R87FDRS180M4,R87FDRS180S4,R87FDRS200L4,R87FDRS71D4,R87FDRS71M4,R87FDRS71MS4,R87FDRS71S4,R87FDRS80K4,R87FDRS80M4,R87FDRS80MK4,R87FDRS80N4,R87FDRS80S4,R87FDRS90L4,R87FDRS90M4,R87FDRS90S4,R87FDT100L4,R87FDT100LC4,R87FDT100LS4,R87FDT100M4,R87FDT112M4,R87FDT132L4,R87FDT132M4,R87FDT132MC4,R87FDT132ML4,R87FDT132S4,R87FDT160L4,R87FDT160M4,R87FDT160MC4,R87FDT160S4,R87FDT180L4,R87FDT180LC4,R87FDT180M4,R87FDT180S4,R87FDT200L4,R87FDT71D4,R87FDT71M4,R87FDT71MS4,R87FDT71S4,R87FDT80K4,R87FDT80M4,R87FDT80MK4,R87FDT80N4,R87FDT80S4,R87FDT90L4,R87FDT90M4,R87FDT90S4,R87FDV100L4,R87FDV100LC4,R87FDV100LS4,R87FDV100M4,R87FDV112M4,R87FDV132L4,R87FDV132M4,R87FDV132MC4,R87FDV132ML4,R87FDV132S4,R87FDV160L4,R87FDV160M4,R87FDV160MC4,R87FDV160S4,R87FDV180L4,R87FDV180LC4,R87FDV180M4,R87FDV180S4,R87FDV200L4,R87FDV71D4,R87FDV71M4,R87FDV71MS4,R87FDV71S4,R87FDV80K4,R87FDV80M4,R87FDV80MK4,R87FDV80N4,R87FDV80S4,R87FDV90L4,R87FDV90M4,R87FDV90S4,R87FDVE100L4,R87FDVE100LC4,R87FDVE100LS4,R87FDVE100M4,R87FDVE112M4,R87FDVE132L4,R87FDVE132M4,R87FDVE132MC4,R87FDVE132ML4,R87FDVE132S4,R87FDVE160L4,R87FDVE160M4,R87FDVE160MC4,R87FDVE160S4,R87FDVE180L4,R87FDVE180LC4,R87FDVE180M4,R87FDVE180S4,R87FDVE200L4,R87FDVE71D4,R87FDVE71M4,R87FDVE71MS4,R87FDVE71S4,R87FDVE80K4,R87FDVE80M4,R87FDVE80MK4,R87FDVE80N4,R87FDVE80S4,R87FDVE90L4,R87FDVE90M4,R87FDVE90S4,R87F-Y0.37KW,R87F-Y0.55KW,R87F-Y0.75KW,R87F-Y1.1KW,R87F-Y1.5KW,R87F-Y100M4,R87F-Y112M4,R87F-Y11KW,R87F-Y132M4,R87F-Y15KW,R87F-Y160M4,R87F-Y18.5KW,R87F-Y180M4,R87F-Y2.2KW,R87F-Y200M4,R87F-Y22KW,R87F-Y30KW,R87F-Y3KW,R87F-Y4KW,R87F-Y5.5KW,R87F-Y7.5KW,R87F-Y71M4,R87F-Y80M4,R87F-Y90M4,R87F-YEJ0.37KW,R87F-YEJ0.55KW,R87F-YEJ0.75KW,R87F-YEJ1.1KW,R87F-YEJ1.5KW,R87F-YEJ100M4,R87F-YEJ112M4,R87F-YEJ11KW,R87F-YEJ132M4,R87F-YEJ15KW,R87F-YEJ160M4,R87F-YEJ18.5KW,R87F-YEJ180M4,R87F-YEJ2.2KW,R87F-YEJ200M4,R87F-YEJ22KW,R87F-YEJ30KW,R87F-YEJ3KW,R87F-YEJ4KW,R87F-YEJ5.5KW,R87F-YEJ7.5KW,R87F-YEJ71M4,R87F-YEJ80M4,R87F-YEJ90M4,R87F-YVP0.37KW,R87F-YVP0.55KW,R87F-YVP0.75KW,R87F-YVP1.1KW,R87F-YVP1.5KW,R87F-YVP100M4,R87F-YVP112M4,R87F-YVP11KW,R87F-YVP132M4,R87F-YVP15KW,R87F-YVP160M4,R87F-YVP18.5KW,R87F-YVP180M4,R87F-YVP2.2KW,R87F-YVP200M4,R87F-YVP22KW,R87F-YVP30KW,R87F-YVP3KW,R87F-YVP4KW,R87F-YVP5.5KW,R87F-YVP7.5KW,R87F-YVP71M4,R87F-YVP80M4,R87F-YVP90M4,R87F-YVPEJ0.37KW,R87F-YVPEJ0.55KW,R87F-YVPEJ0.75KW,R87F-YVPEJ1.1KW,R87F-YVPEJ1.5KW,R87F-YVPEJ100M4,R87F-YVPEJ112M4,R87F-YVPEJ11KW,R87F-YVPEJ132M4,R87F-YVPEJ15KW,R87F-YVPEJ160M4,R87F-YVPEJ18.5KW,R87F-YVPEJ180M4,R87F-YVPEJ2.2KW,R87F-YVPEJ200M4,R87F-YVPEJ22KW,R87F-YVPEJ30KW,R87F-YVPEJ3KW,R87F-YVPEJ4KW,R87F-YVPEJ5.5KW,R87F-YVPEJ7.5KW,R87F-YVPEJ71M4,R87F-YVPEJ80M4,R87F-YVPEJ90M4。
R88系列減速機參數大全：同軸斜齒輪減速電機
R88減速機配0.37KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R87Y0.37KW | 246.54 | 0.37KW | 73.5kg | 20000N |
| R87Y0.37KW | 216.54 | 0.37KW | 73.5kg | 20000N |
| R87Y0.37KW | 205.71 | 0.37KW | 73.5kg | 20000N |
| R87Y0.37KW | 181.77 | 0.37KW | 73.5kg | 20000N |
| R87Y0.37KW | 155.34 | 0.37KW | 73.5kg | 20000N |
| R87Y0.37KW | 142.41 | 0.37KW | 73.5kg | 20000N |
R88減速機配0.55KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R87F-Y0.55KW | 246.54 | 0.55KW | 78kg | 20000N |
| R87F-Y0.55KW | 216.54 | 0.55KW | 78kg | 20000N |
| R87F-Y0.55KW | 205.71 | 0.55KW | 78kg | 20000N |
| R87F-Y0.55KW | 181.77 | 0.55KW | 78kg | 20000N |
| R87F-Y0.55KW | 155.34 | 0.55KW | 78kg | 20000N |
| R87F-Y0.55KW | 142.41 | 0.55KW | 78kg | 20000N |
| R87F-Y0.55KW | 124.97 | 0.55KW | 78kg | 20000N |
| R87F-Y0.55KW | 118.43 | 0.55KW | 78kg | 20000N |
| R87F-Y0.55KW | 103.65 | 0.55KW | 78kg | 20000N |
R88減速機配0.75KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R87F-Y0.75KW | 246.54 | 0.75KW | 79kg | 18800N |
| R87F-Y0.75KW | 216.54 | 0.75KW | 79kg | 19500N |
| R87F-Y0.75KW | 205.71 | 0.75KW | 79kg | 19700N |
| R87F-Y0.75KW | 181.77 | 0.75KW | 79kg | 20000N |
| R87F-Y0.75KW | 155.34 | 0.75KW | 79kg | 20000N |
| R87F-Y0.75KW | 142.41 | 0.75KW | 79kg | 20000N |
| R87F-Y0.75KW | 124.97 | 0.75KW | 79kg | 20000N |
| R87F-Y0.75KW | 118.43 | 0.75KW | 79kg | 20000N |
| R87F-Y0.75KW | 103.65 | 0.75KW | 79kg | 20000N |
| R87F-Y0.75KW | 93.38 | 0.75KW | 79kg | 20000N |
R88減速機配1.1KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R87F-Y1.1KW | 216.54 | 1.1KW | 83kg | 16600N |
| R87F-Y1.1KW | 205.71 | 1.1KW | 83kg | 17100N |
| R87F-Y1.1KW | 181.77 | 1.1KW | 83kg | 18200N |
| R87F-Y1.1KW | 155.34 | 1.1KW | 83kg | 19200N |
| R87F-Y1.1KW | 142.41 | 1.1KW | 83kg | 19600N |
| R87F-Y1.1KW | 124.97 | 1.1KW | 83kg | 20000N |
| R87F-Y1.1KW | 118.43 | 1.1KW | 83kg | 20000N |
| R87F-Y1.1KW | 103.65 | 1.1KW | 83kg | 20000N |
| R87F-Y1.1KW | 93.38 | 1.1KW | 83kg | 20000N |
| R87F-Y1.1KW | 81.92 | 1.1KW | 83kg | 20000N |
| R87F-Y1.1KW | 72.57 | 1.1KW | 83kg | 20000N |
| R87F-Y1.1KW | 63.68 | 1.1KW | 83kg | 20000N |
| R87F-Y1.1KW | 60.35 | 1.1KW | 83kg | 20000N |
| R87F-Y1.1KW | 52.82 | 1.1KW | 83kg | 20000N |
R88減速機配1.5KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R87F-Y1.5KW | 181.77 | 1.5KW | 86kg | 13200N |
| R87F-Y1.5KW | 155.34 | 1.5KW | 86kg | 16900N |
| R87F-Y1.5KW | 142.41 | 1.5KW | 86kg | 17700N |
| R87F-Y1.5KW | 124.97 | 1.5KW | 86kg | 18700N |
| R87F-Y1.5KW | 118.43 | 1.5KW | 86kg | 19000N |
| R87F-Y1.5KW | 103.65 | 1.5KW | 86kg | 19700N |
| R87F-Y1.5KW | 93.38 | 1.5KW | 86kg | 20000N |
| R87F-Y1.5KW | 81.92 | 1.5KW | 86kg | 20000N |
| R87F-Y1.5KW | 72.57 | 1.5KW | 86kg | 20000N |
| R87F-Y1.5KW | 63.68 | 1.5KW | 86kg | 20000N |
| R87F-Y1.5KW | 60.35 | 1.5KW | 86kg | 20000N |
| R87F-Y1.5KW | 52.82 | 1.5KW | 86kg | 20000N |
| R87F-Y1.5KW | 47.58 | 1.5KW | 86kg | 20000N |
| R87F-Y1.5KW | 41.74 | 1.5KW | 86kg | 20000N |
| R87F-Y1.5KW | 36.84 | 1.5KW | 86kg | 20000N |
R88減速機配2.2KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R87F-Y2.2KW | 124.97 | 2.2KW | 96kg | 11700N |
| R87F-Y2.2KW | 118.43 | 2.2KW | 96kg | 15400N |
| R87F-Y2.2KW | 103.65 | 2.2KW | 96kg | 17100N |
| R87F-Y2.2KW | 93.38 | 2.2KW | 96kg | 18000N |
| R87F-Y2.2KW | 81.92 | 2.2KW | 96kg | 18900N |
| R87F-Y2.2KW | 72.57 | 2.2KW | 96kg | 19600N |
| R87F-Y2.2KW | 63.68 | 2.2KW | 96kg | 20000N |
| R87F-Y2.2KW | 60.35 | 2.2KW | 96kg | 20000N |
| R87F-Y2.2KW | 52.82 | 2.2KW | 96kg | 20000N |
| R87F-Y2.2KW | 47.58 | 2.2KW | 96kg | 20000N |
| R87F-Y2.2KW | 41.74 | 2.2KW | 96kg | 19800N |
| R87F-Y2.2KW | 36.84 | 2.2KW | 96kg | 19100N |
| R87F-Y2.2KW | 32.66 | 2.2KW | 96kg | 18500N |
| R87F-Y2.2KW | 34.4 | 2.2KW | 96kg | 18800N |
| R87F-Y2.2KW | 31.4 | 2.2KW | 96kg | 18300N |
| R87F-Y2.2KW | 27.84 | 2.2KW | 96kg | 17600N |
| R87F-Y2.2KW | 23.4 | 2.2KW | 96kg | 16700N |
| R87F-Y2.2KW | 21.51 | 2.2KW | 96kg | 16300N |
R88減速機配3KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R87F-Y3KW | 93.38 | 3KW | 98kg | 12000N |
| R87F-Y3KW | 81.92 | 3KW | 98kg | 16500N |
| R87F-Y3KW | 72.57 | 3KW | 98kg | 17700N |
| R87F-Y3KW | 63.68 | 3KW | 98kg | 18700N |
| R87F-Y3KW | 60.35 | 3KW | 98kg | 19000N |
| R87F-Y3KW | 52.82 | 3KW | 98kg | 19700N |
| R87F-Y3KW | 47.58 | 3KW | 98kg | 19800N |
| R87F-Y3KW | 41.74 | 3KW | 98kg | 19200N |
| R87F-Y3KW | 36.84 | 3KW | 98kg | 18500N |
| R87F-Y3KW | 32.66 | 3KW | 98kg | 17900N |
| R87F-Y3KW | 27.88 | 3KW | 98kg | 17200N |
| R87F-Y3KW | 34.4 | 3KW | 98kg | 18200N |
| R87F-Y3KW | 31.4 | 3KW | 98kg | 17800N |
| R87F-Y3KW | 27.84 | 3KW | 98kg | 17200N |
| R87F-Y3KW | 23.4 | 3KW | 98kg | 16300N |
| R87F-Y3KW | 21.51 | 3KW | 98kg | 15900N |
| R87F-Y3KW | 19.1 | 3KW | 98kg | 15400N |
| R87F-Y3KW | 17.08 | 3KW | 98kg | 14900N |
| R87F-Y3KW | 15.35 | 3KW | 98kg | 14400N |
R88減速機配4KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R87F-Y4KW | 63.68 | 4KW | 109kg | 13600N |
| R87F-Y4KW | 60.35 | 4KW | 109kg | 14200N |
| R87F-Y4KW | 52.82 | 4KW | 109kg | 15500N |
| R87F-Y4KW | 47.58 | 4KW | 109kg | 16200N |
| R87F-Y4KW | 41.74 | 4KW | 109kg | 17000N |
| R87F-Y4KW | 36.84 | 4KW | 109kg | 17500N |
| R87F-Y4KW | 32.66 | 4KW | 109kg | 17400N |
| R87F-Y4KW | 27.88 | 4KW | 109kg | 16700N |
| R87F-Y4KW | 34.4 | 4KW | 109kg | 17600N |
| R87F-Y4KW | 31.4 | 4KW | 109kg | 17200N |
| R87F-Y4KW | 27.84 | 4KW | 109kg | 16700N |
| R87F-Y4KW | 23.4 | 4KW | 109kg | 16000N |
| R87F-Y4KW | 21.51 | 4KW | 109kg | 15600N |
| R87F-Y4KW | 19.1 | 4KW | 109kg | 15100N |
| R87F-Y4KW | 17.08 | 4KW | 109kg | 14600N |
| R87F-Y4KW | 15.35 | 4KW | 109kg | 14200N |
| R87F-Y4KW | 13.33 | 4KW | 109kg | 13600N |
| R87F-Y4KW | 11.93 | 4KW | 109kg | 13200N |
R88減速機配5.5KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R87F-Y5.5KW | 47.58 | 5.5KW | 123kg | 15700N |
| R87F-Y5.5KW | 41.74 | 5.5KW | 123kg | 17200N |
| R87F-Y5.5KW | 36.84 | 5.5KW | 123kg | 17100N |
| R87F-Y5.5KW | 32.66 | 5.5KW | 123kg | 16700N |
| R87F-Y5.5KW | 27.88 | 5.5KW | 123kg | 16100N |
| R87F-Y5.5KW | 27.84 | 5.5KW | 123kg | 16100N |
| R87F-Y5.5KW | 23.4 | 5.5KW | 123kg | 15400N |
| R87F-Y5.5KW | 21.51 | 5.5KW | 123kg | 15100N |
| R87F-Y5.5KW | 19.1 | 5.5KW | 123kg | 14600N |
| R87F-Y5.5KW | 17.08 | 5.5KW | 123kg | 14200N |
| R87F-Y5.5KW | 15.35 | 5.5KW | 123kg | 13800N |
| R87F-Y5.5KW | 13.33 | 5.5KW | 123kg | 13300N |
| R87F-Y5.5KW | 11.93 | 5.5KW | 123kg | 12900N |
| R87F-Y5.5KW | 9.9 | 5.5KW | 123kg | 12200N |
| R87F-Y5.5KW | 9.14 | 5.5KW | 123kg | 12100N |
| R87F-Y5.5KW | 8.22 | 5.5KW | 123kg | 11700N |
| R87F-Y5.5KW | 7.13 | 5.5KW | 123kg | 11200N |
R88減速機配7.5KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R87F-Y7.5KW | 36.84 | 7.5KW | 136kg | 14800N |
| R87F-Y7.5KW | 32.66 | 7.5KW | 136kg | 15600N |
| R87F-Y7.5KW | 27.88 | 7.5KW | 136kg | 15200N |
| R87F-Y7.5KW | 27.84 | 7.5KW | 136kg | 15200N |
| R87F-Y7.5KW | 23.4 | 7.5KW | 136kg | 14600N |
| R87F-Y7.5KW | 21.51 | 7.5KW | 136kg | 14400N |
| R87F-Y7.5KW | 19.1 | 7.5KW | 136kg | 14000N |
| R87F-Y7.5KW | 17.08 | 7.5KW | 136kg | 13600N |
| R87F-Y7.5KW | 15.35 | 7.5KW | 136kg | 12600N |
| R87F-Y7.5KW | 13.33 | 7.5KW | 136kg | 12800N |
| R87F-Y7.5KW | 11.93 | 7.5KW | 136kg | 12500N |
| R87F-Y7.5KW | 9.9 | 7.5KW | 136kg | 11900N |
| R87F-Y7.5KW | 9.14 | 7.5KW | 136kg | 11800N |
| R87F-Y7.5KW | 8.22 | 7.5KW | 136kg | 11500N |
| R87F-Y7.5KW | 7.13 | 7.5KW | 136kg | 11000N |
| R87F-Y7.5KW | 6.39 | 7.5KW | 136kg | 10700N |
| R87F-Y7.5KW | 5.3 | 7.5KW | 136kg | 10100N |
R88減速機配11KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R87F-Y11KW | 21.51 | 11KW | 178kg | 13200N |
| R87F-Y11KW | 19.1 | 11KW | 178kg | 12900N |
| R87F-Y11KW | 17.08 | 11KW | 178kg | 12700N |
| R87F-Y11KW | 15.35 | 11KW | 178kg | 12500N |
| R87F-Y11KW | 13.33 | 11KW | 178kg | 12100N |
| R87F-Y11KW | 11.93 | 11KW | 178kg | 11800N |
| R87F-Y11KW | 9.9 | 11KW | 178kg | 11300N |
| R87F-Y11KW | 9.14 | 11KW | 178kg | 11400N |
| R87F-Y11KW | 8.22 | 11KW | 178kg | 11100N |
| R87F-Y11KW | 7.13 | 11KW | 178kg | 10700N |
| R87F-Y11KW | 6.39 | 11KW | 178kg | 10400N |
| R87F-Y11KW | 5.3 | 11KW | 178kg | 9840N |
R88減速機配15KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R87F-Y15KW | 17.08 | 15KW | 198kg | 11600N |
| R87F-Y15KW | 15.35 | 15KW | 198kg | 11500N |
| R87F-Y15KW | 13.33 | 15KW | 198kg | 11300N |
| R87F-Y15KW | 11.93 | 15KW | 198kg | 11100N |
| R87F-Y15KW | 9.9 | 15KW | 198kg | 10700N |
| R87F-Y15KW | 9.14 | 15KW | 198kg | 11000N |
| R87F-Y15KW | 8.22 | 15KW | 198kg | 10700N |
| R87F-Y15KW | 7.13 | 15KW | 198kg | 10300N |
| R87F-Y15KW | 6.39 | 15KW | 198kg | 10100N |
| R87F-Y15KW | 5.3 | 15KW | 198kg | 9590N |
R88減速機配18.5KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R87F-Y18.5KW | 13.33 | 18.5KW | 235Kg | 10600N |
| R87F-Y18.5KW | 11.93 | 18.5KW | 235Kg | 10400N |
| R87F-Y18.5KW | 9.9 | 18.5KW | 235Kg | 10200N |
| R87F-Y18.5KW | 9.14 | 18.5KW | 235Kg | 10600N |
| R87F-Y18.5KW | 8.22 | 18.5KW | 235Kg | 10300N |
| R87F-Y18.5KW | 7.13 | 18.5KW | 235Kg | 10000N |
| R87F-Y18.5KW | 6.39 | 18.5KW | 235Kg | 9770N |
| R87F-Y18.5KW | 5.3 | 18.5KW | 235Kg | 9350N |
R88減速機配22KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R87F-Y22KW | 9.9 | 22KW | 248Kg | 9640N |
| R87F-Y22KW | 9.14 | 22KW | 248Kg | 10100N |
| R87F-Y22KW | 8.22 | 22KW | 248Kg | 9950N |
| R87F-Y22KW | 7.13 | 22KW | 248Kg | 9680N |
| R87F-Y22KW | 6.39 | 22KW | 248Kg | 9470N |
| R87F-Y22KW | 5.3 | 22KW | 248Kg | 9100N |
R88減速機生產工廠展示：看廠請聯系微信13827261050，獲取位置，需提前一天預約
推薦類似型號：R78減速機
關鍵詞:同向減速機臥式配電機一體式_R系列減速電機_R系列減速機_R系列減速器_同向減速器_GR型減速機_R向減速機_R系列斜齒輪減速機_GR系列減速機_R型減速機_GR系列斜齒輪減速機
R系列減速機型號：R18減速機,R28減速機,R38減速機,R48減速機,R58減速機,R68減速機,R78減速機,R88減速機,R98減速機,R108減速機,R138減速機,R148減速機,R168減速機
R系列齒輪減速馬達可配變頻電機，剎車電機，防爆電機，伺服電機，交流電機，直流電機，三相電機，單相電機 0.12KW-132KW之間
如需工程師幫選型，請加微信13827261050，留言告知工程師參數要求
標簽: R88減速機 R87臥式硬齒面斜齒輪減速機 R87系列減速機 R87減速機傳動比 R87減速機選型參數 R87減速機CAD三維圖
