S78R38減速機詳細信息
S78R38減速機
訂購熱線：13360667204
S78R38減速機電機功率：S78R38Y0.12KW減速機,S78R38Y0.18KW減速機,S78R38Y0.25KW減速機,S78R38Y0.37KW減速機,S78R38Y0.55KW減速機,S78R38Y0.75KW減速機,S78R38Y1.1KW減速機（可配變頻電機，剎車電機，防爆電機，伺服電機，交流電機，直流電機，三相電機，單相電機）。
S78R38減速機配0.12KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| S78R38-Y0.12KW | 3540 | 0.12KW | 0.39r/min | 1370N.m | 64kg | 7240N | 0.90 |
| S78R38-Y0.12KW | 3098 | 0.12KW | 0.45r/min | 1200N.m | 64kg | 12300N | 1.05 |
| S78R38-Y0.12KW | 2374 | 0.12KW | 0.58r/min | 1320N.m | 64kg | 10600N | 0.95 |
| S78R38-Y0.12KW | 2083 | 0.12KW | 0.66r/min | 1160N.m | 64kg | 12600N | 1.05 |
| S78R38-Y0.12KW | 1813 | 0.12KW | 0.76r/min | 980N.m | 64kg | 13900N | 1.25 |
| S78R38-Y0.12KW | 1745 | 0.12KW | 0.79r/min | 930N.m | 64kg | 14200N | 1.30 |
| S78R38-Y0.12KW | 1600 | 0.12KW | 0.86r/min | 860N.m | 64kg | 14600N | 1.45 |
| S78R38-Y0.12KW | 1404 | 0.12KW | 0.98r/min | 755N.m | 64kg | 15100N | 1.65 |
| S78R38-Y0.12KW | 1245 | 0.12KW | 1.10r/min | 660N.m | 64kg | 15500N | 1.90 |
S78R38減速機配0.18KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| S78R38-Y0.18KW | 1404 | 0.18KW | 0.94r/min | 1240N.m | 64.5kg | 11900N | 1.00 |
| S78R38-Y0.18KW | 1245 | 0.18KW | 1.10r/min | 1090N.m | 64.5kg | 13200N | 1.15 |
| S78R38-Y0.18KW | 1100 | 0.18KW | 1.20r/min | 1020N.m | 64.5kg | 13700N | 1.20 |
| S78R38-Y0.18KW | 954 | 0.18KW | 1.40r/min | 870N.m | 64.5kg | 14500N | 1.40 |
| S78R38-Y0.18KW | 837 | 0.18KW | 1.60r/min | 770N.m | 64.5kg | 15000N | 1.60 |
| S78R38-Y0.18KW | 714 | 0.18KW | 1.80r/min | 640N.m | 64.5kg | 15600N | 1.95 |
| S78R38-Y0.18KW | 637 | 0.18KW | 2.10r/min | 565N.m | 64.5kg | 15800N | 2.20 |
| S78R38-Y0.18KW | 574 | 0.18KW | 2.30r/min | 515N.m | 64.5kg | 16000N | 2.40 |
S78R38減速機配0.25KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| S78R38-Y0.25KW | 954 | 0.25KW | 1.40r/min | 1250N.m | 68.5kg | 11800N | 1.00 |
| S78R38-Y0.25KW | 837 | 0.25KW | 1.60r/min | 1100N.m | 68.5kg | 13100N | 1.10 |
| S78R38-Y0.25KW | 714 | 0.25KW | 1.80r/min | 920N.m | 68.5kg | 14200N | 1.35 |
| S78R38-Y0.25KW | 637 | 0.25KW | 2.00r/min | 820N.m | 68.5kg | 14800N | 1.50 |
| S78R38-Y0.25KW | 574 | 0.25KW | 2.30r/min | 745N.m | 68.5kg | 15200N | 1.65 |
| S78R38-Y0.25KW | 499 | 0.25KW | 2.60r/min | 635N.m | 68.5kg | 15600N | 1.95 |
S78R38減速機配0.37KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| S78R38-Y0.37KW | 714 | 0.37KW | 1.90r/min | 1310N.m | 69kg | 11300N | 0.95 |
| S78R38-Y0.37KW | 637 | 0.37KW | 2.20r/min | 1160N.m | 69kg | 12600N | 1.05 |
| S78R38-Y0.37KW | 574 | 0.37KW | 2.40r/min | 1050N.m | 69kg | 13400N | 1.15 |
| S78R38-Y0.37KW | 499 | 0.37KW | 2.80r/min | 900N.m | 69kg | 14300N | 1.35 |
| S78R38-Y0.37KW | 438 | 0.37KW | 3.20r/min | 795N.m | 69kg | 14900N | 1.55 |
| S78R38-Y0.37KW | 389 | 0.37KW | 3.60r/min | 705N.m | 69kg | 15300N | 1.75 |
S78R38減速機配0.55KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| S78R38-Y0.55KW | 438 | 0.55KW | 3.20r/min | 1200N.m | 73.5kg | 12300N | 1.05 |
| S78R38-Y0.55KW | 389 | 0.55KW | 3.60r/min | 1070N.m | 73.5kg | 13300N | 1.15 |
| S78R38-Y0.55KW | 327 | 0.55KW | 4.20r/min | 900N.m | 73.5kg | 14400N | 1.35 |
| S78R38-Y0.55KW | 289 | 0.55KW | 4.80r/min | 810N.m | 73.5kg | 14800N | 1.50 |
| S78R38-Y0.55KW | 250 | 0.55KW | 5.50r/min | 705N.m | 73.5kg | 15300N | 1.75 |
S78R38減速機配0.75KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| S78R38-Y0.75KW | 327 | 0.75KW | 4.40r/min | 1200N.m | 74.5kg | 12300N | 1.05 |
| S78R38-Y0.75KW | 289 | 0.75KW | 5.00r/min | 1080N.m | 74.5kg | 13200N | 1.15 |
| S78R38-Y0.75KW | 250 | 0.75KW | 5.70r/min | 930N.m | 74.5kg | 14200N | 1.30 |
| S78R38-Y0.75KW | 219 | 0.75KW | 6.60r/min | 820N.m | 74.5kg | 14800N | 1.50 |
S78R38減速機配1.1KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| S78R38-Y1.1KW | 219 | 1.1KW | 6.50r/min | 1230N.m | 78.5kg | 12000N | 1.00 |
S78R38減速器減速比：3540比減速器,3098比蝸輪蝸桿減速機,2374比減速器,2083比減速器,1813比減速器,1745比減速器,1600比減速器,1404比減速器,1245比減速器,1100比減速器,954比減速器,837比減速器,714比減速器,637比減速器,574比減速器,499比減速器,438比減速器,389比減速器,327比減速器,289比減速器,250比減速器,219比減速器
S78R38減速機電機安裝尺寸：輸出軸+鍵Φ48.5（可定做），高301*寬300（帶輸出軸）*長474
S78R38減速電機輸出轉數：0.39轉減速電機,0.45轉減速電機,0.58轉減速電機,0.66轉自鎖減速機,0.76轉減速電機,0.79轉減速電機,0.86轉減速電機,0.94轉減速電機,0.98轉減速電機,1.1轉減速電機,1.2轉減速電機,1.4轉減速電機,1.6轉減速電機,1.8轉減速電機,1.9轉減速電機,2轉減速電機,2.1轉減速電機,2.2轉減速電機,2.3轉減速電機,2.4轉減速電機,2.6轉減速電機,2.8轉減速電機,3.2轉減速電機,3.6轉減速電機,4.2轉減速電機,4.4轉減速電機,4.8轉減速電機,5轉減速電機,5.5轉減速電機,5.7轉減速電機,6.5轉減速電機,6.6轉減速電機。
S78R38減速箱電機輸出扭矩：515N.m減速箱,565N.m減速箱,635N.m減速箱,640N.m減速箱,660N.m減速箱,705N.m減速箱,745N.m減速箱,755N.m減速箱,770N.m減速箱,795N.m減速箱,810N.m減速箱,820N.m減速箱,860N.m減速箱,870N.m減速箱,900N.m減速箱,920N.m減速箱,930N.m減速箱,980N.m減速箱,1020N.m減速箱,1050N.m減速箱,1070N.m減速箱,1080N.m減速箱,1090N.m減速箱,1100N.m減速箱,1160N.m減速箱,1200N.m減速箱,1230N.m減速箱,1240N.m減速箱,1250N.m減速箱,1310N.m減速箱,1320N.m減速箱,1370N.m減速箱。
S78R38減速機電機各種輸出實物圖：
S78R38減速馬達型號：
SHZ77R37DM63L4,SHZ77R37DM63M4,SHZ77R37DM63MS4,SHZ77R37DM63S4,SHZ77R37DM71D4,SHZ77R37DM71M4,SHZ77R37DM71MS4,SHZ77R37DM71S4,SHZ77R37DM80K4,SHZ77R37DM80M4,SHZ77R37DM80MK4,SHZ77R37DM80N4,SHZ77R37DM80S4,SHZ77R37DM90L4,SHZ77R37DM90M4,SHZ77R37DM90S4,SHZ77R37DR63L4,SHZ77R37DR63M4,SHZ77R37DR63MS4,SHZ77R37DR63S4,SHZ77R37DR71D4,SHZ77R37DR71M4,SHZ77R37DR71MS4,SHZ77R37DR71S4,SHZ77R37DR80K4,SHZ77R37DR80M4,SHZ77R37DR80MK4,SHZ77R37DR80N4,SHZ77R37DR80S4,SHZ77R37DR90L4,SHZ77R37DR90M4,SHZ77R37DR90S4,SHZ77R37DRE63L4,SHZ77R37DRE63M4,SHZ77R37DRE63MS4,SHZ77R37DRE63S4,SHZ77R37DRE71D4,SHZ77R37DRE71M4,SHZ77R37DRE71MS4,SHZ77R37DRE71S4,SHZ77R37DRE80K4,SHZ77R37DRE80M4,SHZ77R37DRE80MK4,SHZ77R37DRE80N4,SHZ77R37DRE80S4,SHZ77R37DRE90L4,SHZ77R37DRE90M4,SHZ77R37DRE90S4,SHZ77R37DRN63L4,SHZ77R37DRN63M4,SHZ77R37DRN63MS4,SHZ77R37DRN63S4,SHZ77R37DRN71D4,SHZ77R37DRN71M4,SHZ77R37DRN71MS4,SHZ77R37DRN71S4,SHZ77R37DRN80K4,SHZ77R37DRN80M4,SHZ77R37DRN80MK4,SHZ77R37DRN80N4,SHZ77R37DRN80S4,SHZ77R37DRN90L4,SHZ77R37DRN90M4,SHZ77R37DRN90S4,SHZ77R37DRS63L4,SHZ77R37DRS63M4,SHZ77R37DRS63MS4,SHZ77R37DRS63S4,SHZ77R37DRS71D4,SHZ77R37DRS71M4,SHZ77R37DRS71MS4,SHZ77R37DRS71S4,SHZ77R37DRS80K4,SHZ77R37DRS80M4,SHZ77R37DRS80MK4,SHZ77R37DRS80N4,SHZ77R37DRS80S4,SHZ77R37DRS90L4,SHZ77R37DRS90M4,SHZ77R37DRS90S4,SHZ77R37DT63L4,SHZ77R37DT63M4,SHZ77R37DT63MS4,SHZ77R37DT63S4,SHZ77R37DT71D4,SHZ77R37DT71M4,SHZ77R37DT71MS4,SHZ77R37DT71S4,SHZ77R37DT80K4,SHZ77R37DT80M4,SHZ77R37DT80MK4,SHZ77R37DT80N4,SHZ77R37DT80S4,SHZ77R37DT90L4,SHZ77R37DT90M4,SHZ77R37DT90S4,SHZ77R37DV63L4,SHZ77R37DV63M4,SHZ77R37DV63MS4,SHZ77R37DV63S4,SHZ77R37DV71D4,SHZ77R37DV71M4,SHZ77R37DV71MS4,SHZ77R37DV71S4,SHZ77R37DV80K4,SHZ77R37DV80M4,SHZ77R37DV80MK4,SHZ77R37DV80N4,SHZ77R37DV80S4,SHZ77R37DV90L4,SHZ77R37DV90M4,SHZ77R37DV90S4,SHZ77R37DVE63L4,SHZ77R37DVE63M4,SHZ77R37DVE63MS4,SHZ77R37DVE63S4,SHZ77R37DVE71D4,SHZ77R37DVE71M4,SHZ77R37DVE71MS4,SHZ77R37DVE71S4,SHZ77R37DVE80K4,SHZ77R37DVE80M4,SHZ77R37DVE80MK4,SHZ77R37DVE80N4,SHZ77R37DVE80S4,SHZ77R37DVE90L4,SHZ77R37DVE90M4,SHZ77R37DVE90S4,SHZ77RF37-Y0.12KW,SHZ77RF37-Y0.18KW,SHZ77RF37-Y0.25KW,SHZ77RF37-Y0.37KW,SHZ77RF37-Y0.55KW,SHZ77RF37-Y0.75KW,SHZ77RF37-Y1.1KW,SHZ77RF37-Y63M4,SHZ77RF37-Y71M4,SHZ77RF37-Y80M4,SHZ77RF37-Y90M4,SHZ77RF37-YEJ0.12KW,SHZ77RF37-YEJ0.18KW,SHZ77RF37-YEJ0.25KW,SHZ77RF37-YEJ0.37KW,SHZ77RF37-YEJ0.55KW,SHZ77RF37-YEJ0.75KW,SHZ77RF37-YEJ1.1KW,SHZ77RF37-YEJ63M4,SHZ77RF37-YEJ71M4,SHZ77RF37-YEJ80M4,SHZ77RF37-YEJ90S4,SHZ77RF37-YVP0.12KW,SHZ77RF37-YVP0.18KW,SHZ77RF37-YVP0.25KW,SHZ77RF37-YVP0.37KW,SHZ77RF37-YVP0.55KW,SHZ77RF37-YVP0.75KW,SHZ77RF37-YVP1.1KW,SHZ77RF37-YVP63M4,SHZ77RF37-YVP71M4,SHZ77RF37-YVP80M4,SHZ77RF37-YVP90S4,SHZ77RF37-YVPEJ0.12KW,SHZ77RF37-YVPEJ0.18KW,SHZ77RF37-YVPEJ0.25KW,SHZ77RF37-YVPEJ0.37KW,SHZ77RF37-YVPEJ0.55KW,SHZ77RF37-YVPEJ0.75KW,SHZ77RF37-YVPEJ1.1KW,SHZ77RF37-YVPEJ63M4,SHZ77RF37-YVPEJ71M4,SHZ77RF37-YVPEJ80M4,SHZ77RF37-YVPEJ90S4,SAZ77R37DM63L4,SAZ77R37DM63M4,SAZ77R37DM63MS4,SAZ77R37DM63S4,SAZ77R37DM71D4,SAZ77R37DM71M4,SAZ77R37DM71MS4,SAZ77R37DM71S4,SAZ77R37DM80K4,SAZ77R37DM80M4,SAZ77R37DM80MK4,SAZ77R37DM80N4,SAZ77R37DM80S4,SAZ77R37DM90L4,SAZ77R37DM90M4,SAZ77R37DM90S4,SAZ77R37DR63L4,SAZ77R37DR63M4,SAZ77R37DR63MS4,SAZ77R37DR63S4,SAZ77R37DR71D4,SAZ77R37DR71M4,SAZ77R37DR71MS4,SAZ77R37DR71S4,SAZ77R37DR80K4,SAZ77R37DR80M4,SAZ77R37DR80MK4,SAZ77R37DR80N4,SAZ77R37DR80S4,SAZ77R37DR90L4,SAZ77R37DR90M4,SAZ77R37DR90S4,SAZ77R37DRE63L4,SAZ77R37DRE63M4,SAZ77R37DRE63MS4,SAZ77R37DRE63S4,SAZ77R37DRE71D4,SAZ77R37DRE71M4,SAZ77R37DRE71MS4,SAZ77R37DRE71S4,SAZ77R37DRE80K4,SAZ77R37DRE80M4,SAZ77R37DRE80MK4,SAZ77R37DRE80N4,SAZ77R37DRE80S4,SAZ77R37DRE90L4,SAZ77R37DRE90M4,SAZ77R37DRE90S4,SAZ77R37DRN63L4,SAZ77R37DRN63M4,SAZ77R37DRN63MS4,SAZ77R37DRN63S4,SAZ77R37DRN71D4,SAZ77R37DRN71M4,SAZ77R37DRN71MS4,SAZ77R37DRN71S4,SAZ77R37DRN80K4,SAZ77R37DRN80M4,SAZ77R37DRN80MK4,SAZ77R37DRN80N4,SAZ77R37DRN80S4,SAZ77R37DRN90L4,SAZ77R37DRN90M4,SAZ77R37DRN90S4,SAZ77R37DRS63L4,SAZ77R37DRS63M4,SAZ77R37DRS63MS4,SAZ77R37DRS63S4,SAZ77R37DRS71D4,SAZ77R37DRS71M4,SAZ77R37DRS71MS4,SAZ77R37DRS71S4,SAZ77R37DRS80K4,SAZ77R37DRS80M4,SAZ77R37DRS80MK4,SAZ77R37DRS80N4,SAZ77R37DRS80S4,SAZ77R37DRS90L4,SAZ77R37DRS90M4,SAZ77R37DRS90S4,SAZ77R37DT63L4,SAZ77R37DT63M4,SAZ77R37DT63MS4,SAZ77R37DT63S4,SAZ77R37DT71D4,SAZ77R37DT71M4,SAZ77R37DT71MS4,SAZ77R37DT71S4,SAZ77R37DT80K4,SAZ77R37DT80M4,SAZ77R37DT80MK4,SAZ77R37DT80N4,SAZ77R37DT80S4,SAZ77R37DT90L4,SAZ77R37DT90M4,SAZ77R37DT90S4,SAZ77R37DV63L4,SAZ77R37DV63M4,SAZ77R37DV63MS4,SAZ77R37DV63S4,SAZ77R37DV71D4,SAZ77R37DV71M4,SAZ77R37DV71MS4,SAZ77R37DV71S4,SAZ77R37DV80K4,SAZ77R37DV80M4,SAZ77R37DV80MK4,SAZ77R37DV80N4,SAZ77R37DV80S4,SAZ77R37DV90L4,SAZ77R37DV90M4,SAZ77R37DV90S4,SAZ77R37DVE63L4,SAZ77R37DVE63M4,SAZ77R37DVE63MS4,SAZ77R37DVE63S4,SAZ77R37DVE71D4,SAZ77R37DVE71M4,SAZ77R37DVE71MS4,SAZ77R37DVE71S4,SAZ77R37DVE80K4,SAZ77R37DVE80M4,SAZ77R37DVE80MK4,SAZ77R37DVE80N4,SAZ77R37DVE80S4,SAZ77R37DVE90L4,SAZ77R37DVE90M4,SAZ77R37DVE90S4,SAZ77RF37-Y0.12KW,SAZ77RF37-Y0.18KW,SAZ77RF37-Y0.25KW,SAZ77RF37-Y0.37KW,SAZ77RF37-Y0.55KW,SAZ77RF37-Y0.75KW,SAZ77RF37-Y1.1KW,SAZ77RF37-Y63M4,SAZ77RF37-Y71M4,SAZ77RF37-Y80M4,SAZ77RF37-Y90M4,SAZ77RF37-YEJ0.12KW,SAZ77RF37-YEJ0.18KW,SAZ77RF37-YEJ0.25KW,SAZ77RF37-YEJ0.37KW,SAZ77RF37-YEJ0.55KW,SAZ77RF37-YEJ0.75KW,SAZ77RF37-YEJ1.1KW,SAZ77RF37-YEJ63M4,SAZ77RF37-YEJ71M4,SAZ77RF37-YEJ80M4,SAZ77RF37-YEJ90S4,SAZ77RF37-YVP0.12KW,SAZ77RF37-YVP0.18KW,SAZ77RF37-YVP0.25KW,SAZ77RF37-YVP0.37KW,SAZ77RF37-YVP0.55KW,SAZ77RF37-YVP0.75KW,SAZ77RF37-YVP1.1KW,SAZ77RF37-YVP63M4,SAZ77RF37-YVP71M4,SAZ77RF37-YVP80M4,SAZ77RF37-YVP90S4,SAZ77RF37-YVPEJ0.12KW,SAZ77RF37-YVPEJ0.18KW,SAZ77RF37-YVPEJ0.25KW,SAZ77RF37-YVPEJ0.37KW,SAZ77RF37-YVPEJ0.55KW,SAZ77RF37-YVPEJ0.75KW,SAZ77RF37-YVPEJ1.1KW,SAZ77RF37-YVPEJ63M4,SAZ77RF37-YVPEJ71M4,SAZ77RF37-YVPEJ80M4,SAZ77RF37-YVPEJ90S4。
S78R38減速電機生產廠家展示：看廠請聯系微信13827261050，獲取位置，需提前一天預約http://www.yijingkt.com/product/list-sxiliejiansuji-cn.html
推薦型號：S78減速機
關鍵詞:G系列減速機一體式_S系列斜齒輪蝸輪蝸桿減速機_S系列減速機_減速機配司服電機連接_S型減速機_司服電機減速機_S系列減速機器_司服減速機
S系列減速機型號：S38減速機,S48減速機,S58減速機,S68減速機,S78減速機,S88減速機,S98齒輪減速馬達
S系列自鎖減速機可配變頻電機，剎車電機，防爆電機，伺服電機，交流電機，直流電機，三相電機，單相電機 0.12KW-22KW之間
如需工程師幫選型，請加微信13827261050，留言告知工程師參數要求
